WyreStorm SW-660-TX-W - 6-Input 4K60 Wireless Presentation Switcher

The WyreStorm SW-660-TX-W is an extremely capable BYOD presentation switcher, built for medium-to-large conference rooms and university classrooms. It expands on the existing SW-640L-TX-W platform with two additional HDMI inputs, giving six total wired inputs (2x USB-C with MST/Dynamic 100W PD and 4x HDMI). Dual HDMI outputs support both matrix switching (4K60 on OUT1, 4K30 on OUT2) and extended-desktop operation via USB-C MST. Four USB 3.0 inputs, dual isolatable Ethernet ports, and wireless casting/conferencing via the WyreStorm APO-DG2 or APO-DG2-PRO round out a flexible, IT-friendly platform. NHD or NDI stream mirroring allow for integration with existing streaming platforms and USB matrix allows selection of connected USB devices.

Features
• Provides 2 USB-C and 4 HDMI inputs, plus 2 HDMI outputs
• USB-C inputs support dynamic charging up to 100W
• Supports 2 HDMI outputs in single view, or 1 HDMI output in up to quadruple view
• Supports input resolutions up to 4K@30Hz 4:4:4
• Supports output resolutions up to 4K@60Hz 4:4:4 (HDMI OUT 1 only)
• Fast switching for both single and Multiview mode
• Built-in Wi-Fi modules for wireless connectivity from Airplay or Miracast Source
• Supports wireless casting with APO-DG2 dongle (sold seperatley)
• Built-in quintuple USB 3.0 switcher allows for USB switching among five USB hosts
• Two Ethernet ports for networking flexibility and security
• RS-232 and relay output for peripherals
• Detailed and friendly OSD information
• Multiple control approaches: front panel buttons, Web UI and Telnet API
