Description
The WyreStorm NHD-600-E-RX decoder delivers cost-optimized, high-performance SDVoE AV over IP transmission and reception. The “E” variation removes some of the I/O found on the standard encoder and decoder and retain only the core functionalities that suite most applications. Engineered for installations requiring pixel-perfect 4K60 4:4:4 video with zero-frame latency, this series supports robust 10GbE network operation with PoE+ power and a flexible AV control suite.
Designed as the economic extension of the NHD-600 family, the NHD-600-E enables integrators to deploy reliable AV distribution for point-to-point and scalable matrix applications without unnecessary complexity or cost.
Features
• Lossless SDVoE video transmission over standard 10GbE networks
• Supports resolutions up to 4096×2160 @ 60Hz
• Full HDMI 2.0 and HDCP 2.2/2.3 compliance
• True zero-frame latency for real-time AV applications
• Point-to-point extender and scalable IP matrix operation
• PoE+ (802.3at) power support for simplified installation
• Flexible EDID management for source compatibility
• Bidirectional IR passthrough over the network
• Bidirectional RS-232 passthrough over the network
• HDMI audio pass-through with multi-channel support
• Analog audio de-embedding and routing
• Compatible with managed 10GbE network switches
• Auto-pairing support for fast point-to-point setup
• Fail-safe firmware upgrade protection
• 5 year warranty
