Description
The WyreStorm EX-70-H2L is a professional HDMI 2.0 HDBaseT extender designed to transmit 4K60 video, audio, and control signals up to 70 meters over a single Cat cable. Supporting HDMI loop-out, RS-232 pass-through, bi-directional IR, and audio de-embedding, the extender enables flexible AV system integration while maintaining full 18Gbps HDMI bandwidth. Ideal for conference rooms, classrooms, and commercial AV environments, the EX-70-H2L delivers reliable long-distance signal extension with simplified installation through bi-directional Power over Cable (PoC).
Features
• Supports HDMI 2.0 with resolution up to 3840x2160 at 60Hz 4:4:4
• Transmitter includes an HDMI loop-out port that mirrors the input signal locally
• Extends video, audio, and control signals up to 70m over a single Cat5e/6 cable
• Includes RS-232 pass-through, bi-directional IR control, and audio de-embedding
• EDID management via DIP switch
• Built-in test pattern generator for installation troubleshooting
• Micro-USB firmware upgrade capability
• LED status indicators for system diagnostics
• Locking power connector
Includes
• 1x Transmitter Unit
• 1x Receiver Unit
• 1x 12V 2A Power Supply (multi-region plugs)
• 8x Mounting ears
• 2x 3-Pin Phoenix connectors
• 1x 5-Pin Phoenix connector
• 1x IR Receiver
• 1x IR Transmitter
