Description
The WyreStorm EX-100-KVM-8K KVM Extender is a high-performance connectivity solution designed for multi-media conference halls and professional A/V environments, capable of extending HDMI 2.1 and USB 2.0 signals up to 100 meters (330 feet) over a single Cat6/6a/7 cable using HDBaseT. It supports ultra-high-definition video up to 8K@30Hz (or 8K@60Hz 4:2:0) and 4K@120Hz (4:4:4), with visually lossless VESA Display Stream Compression (DSC) ensuring signal quality. The system includes both a Transmitter (TX) and a Receiver (RX) unit, featuring RS232 pass-through for device control, integrated USB 2.0 extension for KVM functionality, balanced de-embedded audio output via a 5-pin phoenix connector, and convenient one-way Power over Cable (POC) from the RX to the TX unit.
Features
• Supports HDCP 2.3 for secure content transmission
• Compatible with HDR 10 for enhanced dynamic range and color depth
• Supports high-fidelity audio, including up to 7.1ch formats
• Flexible EDID settings with support for both Copy EDID and Fixed EDID settings
• Features DIP switches on both the TX and RX units for easy setup and control
• Firmware can be updated via both RS232 and Micro USB ports
• Each of the 4 USB device ports on the RX unit provides a maximum current of 1.25A
• Built with a durable sheet steel chassis and a black paint finish
• Designed for wall mounting using the provided mounting ears
• 5 year warranty
