The Theatrixx XVVR-OPTO3 DMX/RDM splitter is a high quality, rugged distribution device for your DMX-512 and RDM signals, with 8 XLR3 outputs.
The 1RU, 8 channel form factor opens up interesting possibilities for high-universe count, high density configurations. For maximal compatibility, the device is offered with a choice of 3-pin or 5-pin XLR connectors.
The input and each output are optically isolated up to 1000 volts, ensuring line failures are contained and do not take down the whole network. RDM data is forwarded to each port, and a special Timing Safe Mode bypasses RDM transmission and boosts the DMX signal quality to ensure compatibility with older generation fixtures. It is also a handy troubleshooting feature that can be easily switched on or off at the push of a button.
Features
• Compatible with DMX-512A (RDM) and DMX-512 (1990)
• Comprehensive protection against severe electrical faults on DMX lines
• Switchable DMX termination on input
• Timing-safe mode filters and retimes incoming signal
• Fully isolated input and output ports
• Multi-function LED status indicator for each port
