The Shure AD8C 8-Port Antenna Combiner streamlines your use of multiple Axient Digital PSM systems at any venue. AD8C combines the RF outputs from up to eight different Axient Digital PSM transmitters into one output to feed a single transmit antenna. AD8C can also combine the RF of up to four Axient Digital PSM transmitters to feed two transmit antennas to support Spatial Diversity. The Shure AD8C 8-Port Combiner enables Automatic Transmitter Compensation with ADTQ or ADTD Axient Digital PSM transmitters, which helps defend against passive signal loss. The AD8C is designed for use with the Axient Digital PSM wireless system.
Features
• 470-960 MHz frequency band
• 8-port passive antenna combiner for Axient Digital PSM
• 8:1 mode combines up to eight RF inputs to a single RF output
• 2x 4:1 mode divides the combiner into two sections, with each section combining up to four RF inputs to a single RF output
• Automatic Transmitter Compensation with Axient Digital PSM transmitters
• Ethernet switch for remote control and firmware updates
• DC module version available to support redundant power
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
FCC CONSUMER ALERT (U.S.)
Most users do not need a license to operate this wireless microphone system. Nevertheless, operating this microphone system without a license is subject to certain restrictions: the system may not cause harmful interference; it must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless microphone systems, and these rules are subject to change. For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC's wireless microphone website at www.fcc.gov/cgb/wirelessmicrophones.
