The Midas DL231 is a 6U 19" fixed-configuration rack I/O unit designed for microphone signal splitting applications with 24 mic/line level inputs and 24 line level outputs, and delivers legendary Midas sound quality utilizing time-tested and road-proven technologies. Featuring two independent Midas microphone preamplifiers with 2.5 dB gain steps per input channel, two dual redundant AES50 network interfaces, dual redundant Ethernet control ports and a MIDI Interface (In, Out, Thru), the DL231 is the ideal partner to the Midas PRO3, PRO6, PRO9, XL8 and PRO X digital consoles, enabling a digital snake connection from Front of House to stage.
Features
• 2 Midas microphone preamplifiers per input with switchable +48 V phantom power
• 2 independent dual redundant AES50 (X and Y) network ports
• 24 electronically balanced output channels
• Remote operation up to 100 m via CAT5/5e cable
• Selectable 96 kHz or 48 kHz sample rate operation
• All settings programmable from front panel controls or console
• PSU status indicator LEDs and configuration LCD display on front panel
• MIDI In, Out and Thru connectors
• Features Neutrik etherCON AES50 network ports
• Rugged 5U rackmount chassis for durability in portable applications
• Dual redundant auto-ranging universal switch-mode power supplies
