The AJA HELO Plus is a compact, advanced H.264 streaming and recording stand-alone appliance. HELO Plus offers both SDI and HDMI I/O with the capability to stream up to 1080p60 to a Content Delivery Network and record simultaneously. Two separate streaming destinations can be set up, and recordings can be made to a combination of SD card, USB storage, and NFS or SMB network storage. HELO Plus also provides Picture-In-Picture and graphics functionality in hardware for compelling presentations made simple.
HELO Plus v.2.0 firmware adds two new features that are optional upgrades with a free trial period, PlayToStream and 4-channel audio support. PlayToStream offers the opportunity to play a live stream out of one encoder and use the other encoder to playback a pre-recorded stream. 4-channel audio support means that you can stream two separate audio pairs via each encode, for multi-language support.
HELO Plus offers high quality streaming with ultra-reliable performance for any critical streaming service needs, including eSports, news, sports, education, creator, live events, and beyond.
Features
- Portable streaming with 3G-SDI and HDMI video I/O
- Encode up to 1080p60 in H.264/MPEG-4
- Web-based GUI preview window
- Stream to two separate destinations simultaneously
- Create Picture-in-Picture streaming/recording output from multiple input sources
- 2-channel stereo audio
- Optional 4-ch audio adds a second stereo pair for streaming alternate languages
- Optional PlayToStream to stream pre-recorded program
- Analog stereo audio out
- Front panel LED audio meters
- Data rates from 100 kbps to 20 Mbps in MPEG-4
- Record to SD, SDHC, or SDXC cards, USB storage, NFS, CIFS, or SMB network volumes
- Front-mounted USB slot and SD card slot for local external storage
- Support for RTP/UDP, RTSP, RTMP, RTMPS, HLS, and Unicast
- SRT compatibility - Caller and Listener modes
- AV Mute with user graphics upload support for pre-live feeds
- Group control for multiple HELO Plus and Ki Pro devices
- Multi-language UI can be selected between English, Japanese, Korean and Chinese
- 3 Year Warranty
